For a complete description of the GTX 327 Mode A/C Transponder, refer
to the GARMIN GTX 327 Mode A/C Transponder Pilot's Guide, P/N 190-
00187-00,Rev. A, or later appropriate revision.
7.2 SYSTEM DESCRIPTION
The GTX 327 unit is located on the instrument panel, in the avionics
column. The transponder antenna is installed on the bottom surface of
thefuselage.
The transponder is connected with the blind encoder, which transfers
altitudedatafromthepitot-staticsystem.
Figure 7-1
Front View of the GTX 327 Unit
ON
STBY
OFF
START
STOP
ALT
12
3
4
5
6
789
0
VFR
IDENT
FUNC
CRSR
CLR
Feb 25, 2005
