AIRCRAFT
SA 160
AIRCRAFTA I R C R A F T
Symphony
6of6
SECTION 9
SUPPLEMENT 5
Feb 25, 2005
Figure 7-1
Front View of the KN 62A Unit
(2) GS/T Mode The unit will hold the internally selected frequency
andwilldisplaydistance,groundspeedandtime-to-station.
(3) RMT Mode The DME will be channeled by selecting NAV
frequency on the NAV receiver. When the unit locks on a ground
station, it will display distance, groundspeed and time-to-station.
Priorto lockon,“dashes”willbedisplayed.
With the frequency selection knobs the desired DME ground
stationfrequencyisselected.
(1) The outer, larger knob changes the larger digits (1 MHz, 10
MHz).
(2) The smaller knob changes the 0.1 MHz digit (0.0, 0.1, 0.2,
etc.). When pulled “out”, it adds 0.05 MHz to the frequency and
tunes in 0.1 MHz steps (0.05, 0.15, 0.25, etc.). Pushing this knob
“in”subtracts0.05MHzfromdisplayedfrequency.
Distance
Ground Speed
Time to Station
