| General descriptions, dangers and warnings

Position Description Symbol

Other

labels

Cooler sticker

Reversible heat pump sticker

Silencer sticker

Inspection sticker

Humidifier sticker

Mounting point sticker

Informative installation sticker

Component stickers

D.1.2 Warnings about dangers

Pictograms according to EN1886

Warning

Warning about danger by rotating parts

Warning

Warning about danger by electricity

211728 | v7.2
