Annex 1 Technical data – unique data for every unit (in separate cover)
Printed on separate pages and delivered with every unit. Enclosed in separate cover.
Annex 2 Assembly of base frame – height 118 mm for unit sizes 10 – 18
Note:
Information about assembly is available in a 2–minutes video on YouTube.
https://youtu.be/B3nX-x7KnrQ
A = Corner
B = Splice
C = Length profile
D = End profile (width of base frame)
D1 = Middle profile
2.1 Base frame length 482 – 2564 [mm] Unit size 10 – 18
