General descriptions, dangers and warnings |
7
Warning
Warning about danger by heat
Warning
Disregards of instructions shown on warning signs are connected by risk for injury or damage on material.
D.1.3 Machine card with unique data on every unit
Machine card contains an important information about the unit. An example of a machine card is shown below.
Product name informs about the unit size, heat exchanger type, the presence of automation. In this example product
name is Geniox GO12 R D R w/auto, where 12 informs about the size of the unit, letter ‘R’ informs about the heat ex-
changer type, letter ‘D’ informs about the section type (in this example it is double height section), and the second let-
ter ‘R’ informs about the unit version (in this example it is right). Production number (Prod. No.) for the complete unit
consist of manufacturing date (YYMM), item number (xxxxx)and manufacturing number (yyyyyyyyyy).
D.2 Dimensions of the units
See Annex 1 with information about the exact dimensions.
