SystemAir Geniox GO - Page 87

|
79
2. Lift empty section (pos. 2) and place it on top of assembled rotor and lower section (pos. 1).
Important
Make sure not to damage the rotor or sections during lifting procedure.
3. Finish the assembly by fixing 4 locking plates in both section sides (2 plates in front and 2 plates on the back).
211728 | v7.2
