Test Description
On a P25 trunked channel, the network selects whether 1011Hz or 1031Hz is used.
Site display
Shows the channel number, signal strength and system-identity code (SYSCODE)
for the currently registered trunked site.
Site measure
Lists the current trunked site (indicated with an asterisk) and up to six detected adja-
cent sites, with received signal strength (RSSI) information.
Tx Tone Transmits a tone of 1011Hz or 1031Hz on the current P25 channel.
Tx Tone Cal
Transmits a 1011Hz or 1031Hz tone on the current channel with a bit error rate (BER)
of 5%.
1
CNV = conventional, TCH = traffic channel, CCH = control channel
2
ANA = analog, PH1 = P25 Phase 1, PH2 = P25 Phase 2
101
Tait International Ltd July 2021
