EVERY CALL COUNTS 43
The following are examples of dial plans using the Routing Table.
Simple Dial Plan
Customer requirements
Process the call after any seven-digit number is dialed or if the Operator is dialed - 0.
From the above table, if the user dials 0 as the first digit, the phone will pause for additional digits. After
the pause, if no additional digits are dialed, the phone places a call to the Operator. In addition, after the
user dials any seven digits, the call is processed.
Complex Dial Plan
Customer requirements
Process the call after the local Operator at 0, long distance Operator at 00, a four-digit local extension
number starting with 3, 4 or 5, a seven-digit local number prefixed by an 8, two-digit number preceded by
star (*), a ten-digit long distance number prefixed by 91, or an international number starting with 9011
is dialed.
2nd Dial Tone
Customer requirements
To provide second dial tone after a 9 is dialed, establish a Dial Plan as below.
To change Routing Table parameters:
•Select Routing Table under the Dial Plan Type.
• Enter the desired values into the respective boxes.
• Select the Add Entry button.
Number TRNC Pre Post Pause Extra
0?????? 0 NULL NULL ?, 0.0.0.0
??????? 0 NULL NULL NULL 0.0.0.0
Number TRNC Pre Post Pause Extra
0? 0 NULL NULL ?, 0.0.0.0
00 0 NULL NULL NULL 0.0.0.0
3??? 0 NULL NULL NULL 0.0.0.0
4??? 0 NULL NULL NULL 0.0.0.0
5??? 0 NULL NULL NULL 0.0.0.0
8??????? 0 NULL NULL NULL 0.0.0.0
*?? 0 NULL NULL NULL 0.0.0.0
91?????????? 0 NULL NULL NULL 0.0.0.0
0 9011~ 0 NULL NULL NULL 0.0.0.0
Number TRNC Pre Post Pause Extra
9.~ 0 NULL NULL ?, 0.0.0.0
