1-6-4.
Decoder
Apply
Low
signal
to
J111-2
to
actívate
DBX
Decode
moda.
A.
RMS
Symmetry
Adjustment
(Connectlon:
Fig.
1-6-2)
1.
Apply
a
100
Hz,
300
mV
signa!
to
J110-1
terminal.
2.
Adjust
R135
to
obtain
a
olean
200
Hz
sine-
wave
on
TP01
(sea
Figs.
1-6-5
&
1-6-6).
B.VCA
Symmetry
Adjustment
(Connection:
Fig.
1-6-4)
1.
Apply
a
staircase
wave
signa!
to
TP01
,
and
a
traingle
wave
signa!
to
the
horizontal
input
terminal
on
the
oscilloscope.
2.
Shortcircüit
between
J110-1
and
J110-2.
3.
Adjust
R118
for
a
relatively
straight
hori
zontal
lina
display
on
the
oscilloscope.
(Leve!
deviation:
5
mV
or
less)
C.
Decoding
Leve!
(Connection:
Fig.
1-6-2)
1.
Apply
a
1
kHz,
300
mV
signa!
to
J110-1
terminal.
2.
Adjust
R107
for
a
300
mV
reading
atJ
110-5
terminal.
D.Frequency
Response
(Connection:
Fig.
1-6-2)
1.
Vary
the
signa!
frequency
to
50
Hz
(300
mV)
and
then
to
10
kHz
(300
mV).
2.
Read
the
output
leve!
at
the
J110-5
terminal
for
each
frequency.
The
output
leve!
should
be
within
the
following
limits
with
reference
to
leve!
at
1
kHz.
50
Hz:
+5
dB
±
1
dB
(447
mV
to
602
mV)
10
kHz:
+9.4
dB
±
1
dB
(793
mV
to
997
mV)
5.
Ralease
Rata
Check
(Connection:
Fig.
1-6-3)
Q
^
^
burst
wave
signa!
with
o
cycles
on
and
128
cycles
off.
+
?n
ralease
rata
is
less
than
750
mV
F.
Decode
Effect
Check
(Connection:
Fig.
1-6-2)
'•^PP'y
a
1kHz,
-20dB
signa!
to
J110-1
terminal
2.
Confirm
that
the
leve!
at
J110-5
terminal
is
-300
dB
±0.5
dB
(i.e.,
-20
d8
against
-10
dB
(300
mV)
reference
level).
3.
Apply
a
1
kHz,
O
dB
signa!
to
J110-1
terminal.
4.
Confirm
that
the
level
at
J110-5
terminal
is
+10
dB
±0.5
dB
(i.e.,
+20
dB
against
-10
dB
(300
mV)
reference
level).
G.Other
Channeis
Repeat
procedures
for
channeis
8
using
the
following
adjustment
input/output
termináis.
2
through
points
and
Channel
Decode
mode
L
signal
Input
Output
Test
Point
Adjustment
Point
RMS
VCA
Level
ch1/ch5
J111-2
J110-1
J110-5
TP01
R135
R118
R107
ch2/ch6
J2n-2
J210-1
J210
5
TP02
R235
R218
R207
ch3/ch7
J311
2
J3101
J310-5
TP03
R335
R318
R307
ch4/ch8
J4n-2
J410-1
J410-5
TP04
R435
R438
R407
