GTS Technical Manual
5. March 2013 Edition: V1.10/2013 5-5
Copyright © 2013, Diversey Inc.
05.10.16 handle - switch lever - 455B_V1.00.fm
5.1 Handle
5.1.3 Removing of switch lever
Picture 5: Switch lever
Remove handle cover according to chapter REMOVING OF
HANDLE COVER AND ELECTRONICS.
Remove screw (01/102) for left switch lever and screw (01/102)
for right switch lever.
Remove the switch levers (01/114).
You can only remove both switch levers together.
Remarks
Both levers are the same spare part.
