GTS Technical Manual
5. March 2013 Edition: V1.10/2013 6-6
Copyright © 2013, Diversey Inc.
06.14.31 dashboard - connections - 455B_V1.00.fm
Pos. Plug Description [plug] Pin Description [pin]
1 Main power 1 Main power LED (+3.3VDC)
2 Vacuum ON/OFF 2 Vacuum eco ON/OFF
3 Vacuum ON/OFF 3 Vacuum ON/OFF
4 Vacuum ON/OFF 4 Vacuum ON/OFF (LED green)
5 5-
6 Vacuum ON/OFF 6 Vacuum eco ON/OFF (LED green)
7 7-
8 Dosing ON/OFF 8 Dosing ON/OFF
9 Dosing ON/OFF 9 Dosing ON/OFF (LED green)
10 Status battery 10 Battery status (LED green)
11 Status battery 11 Battery status (LED green)**
12 Status battery 12 Battery status (LED red)**
13 Service 13 Service LED (red)
14 Machine ON/OFF 14 Machine ON/OFF (+24VDC)
15 Machine ON/OFF 15 Machine ON/OFF button
16 Machine Status 16 Machine ON/OFF LED (green)
17 Charger status 17 Charging LED (Yellow)
18 Charger status 18 Charged LED (green)
19 Charger status 19 Charge failed LED (red)
20 Charger 20 GND of charger
Table 1: Dashboard connector description
