GTS Technical Manual
5. March 2013 Edition: V1.10/2013 6-12
Copyright © 2013, Diversey Inc.
06.18.21 electronics - connections - 455B_V1.00.fm
Pos. Plug Description [plug] Pin Description [pin]
1 GND GND 1 GND
2 SM Vacuum motor 1 Vacuum motor
3 BM Brush motor 1 Brush motor
4+24+24VDC 1+24VDC
5 DV Dosing valve 1 Filter +24VDC
5 DP Dosing pump 1 Not used
6 1 Charger communication 1 Charge (yellow)
6 1 Charger communication 2 Charged (green)
6 1 Charger communication 3 Failure (red)
6 1 Charger communication 4 Immobiliser
6 1 Charger communication 5 Immobiliser
6 1 Charger communication 6 GND
7 Foot SW 1
7 Foot SW 2
7 Foot SW Foot switch 3 Foot switch (455B)
7 Foot SW Foot switch 4 Foot switch (455B)
7 Foot SW 5
7 Foot SW 6
8 Dashboard Ribbon cable Refer to chapter DASHBOARD CONNECTIONS
9 USB Type B SMD (for Service Tool)
Table 2: Electronic connector description
