GTS Technical Manual
15. March 2010 Edition: V1.00/2010 5-9
Copyright © 2010, Diversey Inc.
05.0 swingo 855 B Power - mechanics.fm
power electronics).
• Remove cable fixation at base plate.
• Thread out cables from tank cover.
•Close tank cover.
• Remove fixation screw of axle on one side.
• Push out axle (09/101).
• Remove complete cover.
• According to what you need to exchange, remove the existing
parts from the tank cover and place it on the new one.
Mount (Drilling of hole for tank cover axle)
Assemble the tank cover lock at the end of the sequence.
• Position the base plate on the new tank cover.
• Fix the base plate on the tank cover.
• Position the tank cover including base plate correctly on the
tank.
Make sure that the sealings are nicely positioned.
• Drill the hole for the tank axle without pressing the tank cover
down onto the tank (drill with 10 mm).
• Mount the tank cover axle.
• Fix the axle with the screws.
Remarks
Ensure that the flap is positioned between the tank and the base
plate.
• Open tank cover.
• Thread in cable to the tank cover.
Remarks
Ensure that the cables are positioned that way, that they can not
be squeezed by the tank cover.
• Fix cables on the base plate.
• Connect vacuum motor to the connection block (cable from
power electronics).
• Close tank cover and position it on the base plate.
• Open tank cover together with base plate.
• Use the tank cover support.
• Tighten base plate fixation on the LH side.
• Tighten base plate fixation on the tank support side (RH).
