Remarks
Check at the end if the vacuum motor top sealing is positioned
properly, therefore unscrew and remove the dashboard and check.
• Open tank cover.
• Assemble tank cover lock.
Adjustment
Adjust the tank cover lock and ensure a proper opening and closing
of the tank cover.
• Mount the rear panel.
• Assemble handle on the tank cover with the 7 screws.
• Position the complete throttle lever system.
• Thread in the hall sensor cable to the dashboard.
• Fix the throttle lever bracket with the screws.
• Position wires on the external hour counter or on the handle
cover, depending on the setup.
• Mount the handle cover.
• Connect wires to dashboard.
• Assemble dashboard on the tank cover.
