GTS Technical Manual
15. March 2010 Edition: V1.00/2010 6-12
Copyright © 2010, Diversey Inc.
06.0 swingo 855 B Power - electronics.fm
Pos. Plug Description [plug] Pin Description [pin]
1 X15 Brush motor - Minus (-) 1 Minus (-)
2 X13 Brush motor - Plus (+) 1 Plus (+)
3 X14 Battery - 24V 1 24V
4 X16 Battery - GND 1 GND
5X1Drive motor 1Minus (-)
5X1Drive motor 2Plus (+)
6 X2 Vacuum motor 1 Plus (+)
6 X2 Vacuum motor 2 Minus (-)
7 X8 Emergency loop 1 Emergency loop - IN
7 X8 Emergency loop 2 Emergency loop - OUT
8 X12 External hour counter (Optional) 1 Plus
8 X12 External hour counter (Optional) 2 Minus
9 X17 TASKI J-FIT (Optional) 1 Power On
9 X17 TASKI J-FIT (Optional) 2 Power On
9 X17 TASKI J-FIT (Optional) 3 PWM J-FIT OUT
9 X17 TASKI J-FIT (Optional) 4 GND
10 X9 USB port 1 VCC USB
10 X9 USB port 2 Minus
10 X9 USB port 3 Plus
10 X9 USB port 4 GND
Table 2: Power electronics connector description
