GTS Technical Manual
15. March 2010 Edition: V1.00/2010 6-13
Copyright © 2010, Diversey Inc.
06.0 swingo 855 B Power - electronics.fm
10 X9 USB port 5 (Housing) GND
11 X7 Communication 1 Throttle
11 X7 Communication 2 Serial - OUT
11 X7 Communication 3 Serial - CLK
11 X7 Communication 4 Serial - LATCH
11 X7 Communication 5 Serial - IN
11 X7 Communication 6 Start signal
11 X7 Communication 7 +5V
11 X7 Communication 8 GND
11 X7 Communication 9 (Housing) GND
11 X7 Communication 10 (Housing) GND
12 X18 Electrical brush drive unit 1 Motor Plus
12 X18 Electrical brush drive unit 2 Motor Minus
12 X18 Electrical brush drive unit 3 EBU internal switch
12 X18 Electrical brush drive unit 4 EBU internal switch
12 X18 Electrical brush drive unit 5 Brush position switch (Transport = Closed)
12 X18 Electrical brush drive unit 6 Minus (-)
13 X4 Pump 1 1 Duty cycle Pump 1 (1255)
13 X4 Pump 2 2 Duty cycle Pump 2 (755/855 and 1255)
13 X4 Filter 24V 3 Plus (+)
Pos. Plug Description [plug] Pin Description [pin]
Table 2: Power electronics connector description
