TC Electronic SYSTEM 6000 MKII Algorithm Manual

20
nOnlIn-2
Differences are more pronounced with low Diffuse
settings and Twist Ratios.
Diffuse
Range: 0 - 100%
Sets the amount of diffusion applied to the Reverb Style
selected.
ForhighDiffuseratios,theAttackandDecaytimes
ofthereverbEnvelopemaybeslightlyaffected.
Twist Type
Selectswhichtypeoffunkyeffecttreatmenttobeused
on the reverb. Twist Type should be regarded as a spice
capableofsparkingimaginationinthemixprocess.Trythe
effect on all sorts of different sources to add character or
makethemstandout.IfspectralshapingusingtheTwist
parameters get out of control, the Lo and Hi cuts can be
used to stay within limits.
When the Twist Ratio is set at 0%, Twist Type has
no effect.
Twist Ratio
Range: 0 - 100%
Appliestheselectedamountof“Twist”totheReverb.
When the Twist Ratio is set at 0%, Twist Type has
no effect.
Width
Range: 0 - 100%
AdjuststheOutputStereoWidth.0%denotesmono,while
100% is max width.
The perceived width of the effect is also affected
by the Reverb Style and Diffuse parameters. Width
difference between Styles is most obvious at low
Diffuse Ratios.
Levels page
In Level
Range: Off - 0dB
Adjuststheinputlevel.
If radical Style and Twist settings are used, or full
scaleInputsignals,itmaybenecessarytoadjust
the Input level slightly down to avoid overloading the
Outputs. Overloads are shown as a red indication
abovetheEnginenumberontopofthescreen.
High resolution internal processing ensures that
audio quality is not affected, should headroom
adjustmentsbenecessary.
Out Level
Range: Off - 0dB
AdjuststheOutputlevel.
Dry Level
Range: Off - 0dB
AdjuststhedrysignallevelpassedthroughtheEngine.
Foratypicalsend/returnconfiguration,leaveDryleveloff.
Wet Level
Range: Off - 0dB
AdjuststhewetOutputlevel.
Lo Cut
Range:20Hzto20kHz
Lo Cut on the Reverb Input.
Hi Cut
Range:20Hzto20kHz
Hi cut on the Reverb Input.
LoandHiCutcanhelpkeepingheavilyTwisted
processing better under control.
