TC Electronic SYSTEM 6000 MKII Algorithm Manual

96
DElAy - 2
Main
Delay Line 1
Delay 1
Range:1to2500ms
Sets the Delay time for the left side.
Level 1
Range: Off to 0.0dB
The Output level of channel 1.
Pan 1
Range:50L-center-50R
Controls the position of channel 1 in the stereo image.
Delay Line 2
Delay 2
Range:1to2500ms
Sets the Delay time for the right side.
Level 2
Range: Off to 0.0dB
The Output level of channel 2.
Pan 2
Range:50L-center-50R
Controls the position of channel 2 in the stereo image.
Delay EQ
Hi Cut Freq
Range:500Hztoflat
Hi Cut filter, shelving type. Provides an overall high
frequency roll-off (6dB per octave) that is well suited to
maketheDelayeffectsoundwarmer.
Hi Cut Att
Range: -40 to 0.0dB
The attenuation control sets the amount of high frequency
roll-offdeterminedbytheHiCutparameterin0.5dBsteps.
This M5000 algorithm is a 24 bit true stereo effect offering Delays of up to 2.5 sec in each channel with two filtered
feedback controls per channel (self feedback and x feedback). Delays may be modulated with control over
relative L/R phase for Chorus or Tape Delay emulation. The System 6000 implementation of Delay 2 can be used
with sample rates of up to 96kHz.
The Delay - 2 algorithm occupies:
@ Normal Sample Rate : 1/4 DSP Resource
@ Double Sample Rate : 1/4 DSP Resource
Algorithm Inputs/Outputs are distributed as follows:
E1 - E4
L
R
L
R
INPUT
OUTPUT
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
