TC Electronic SYSTEM 6000 MKII Algorithm Manual

79
unwrAP HD
Decorrelate Tone
Range:+/-40steps.
Adjustthetone(color)ofthedecorrelatedpartofthesound
on the surround outputs.
EQ
TheEQfortheCenterchannelfeaturesfour-band
parametricEQwithhigh-andlow-passfiltersswitchable
between Notch, Parametric, Shelving and Cut filters.
Basic operation
• SelectFreq,GainorTypetoaccessthesameparameter
forthefourEQbands.
• SelectLoorHitoaccessthethreeparametersforthe
individualEQband.
• PressBypassEQtobypasstheentireEQ.
Bypass does not affect the selected Contour Style.
Type Selector
o Press Type and use faders 1-4 to select filter types.
ForLoandHifiltersselectbetweenfiltertypes:
Parametric, Notch, Shelve and Cut.
ForMid1andMid2filtersselectbetweenfiltertypes:
Parametric and Notch.
Freq
PressFreqanduseFaders1to4toadjustfrequencyfor
each of the four bands.
Range-Loband  :20Hzto5kHz
Range-Mid1band :20Hzto20kHz
Range-Mid2band :20Hzto20kHz
Range-Hiband  :500Hzto20kHz
Gain
PressGainanduseFaders1-4toadjustgainforeachof
thefourEQbands.
Range for the Parametric, Shelve and Cut type:
LoGain  :-12dBto+12dB
Mid1Gain :-12dBto+12dB
Mid2Gain :-12dBto+12dB
HiGain  :-12dBto+12dB
Range for the Notch filter:
Lo Gain : -100dB to 0dB
Mid1 Gain : -100dB to 0dB
Mid2 Gain : -100dB to 0dB
Hi Gain : -100dB to 0dB
Type
PressanduseFaders1-4tosetBWvalueforeachofthe
4EQbands.
Range for the Notch filter:
Lo BW : 0.02oct to 1oct
Mid1 BW : 0.02oct to 1oct
Mid2 BW : 0.02oct to 1oct
Hi BW : 0.02oct to 1oct
Range for the Parametric filter:
Lo BW : 0.1oct to 4oct
Mid1 BW : 0.1oct to 4oct
Mid2 BW : 0.1oct to 4oct
Hi BW : 0.1oct to 4oct
Range for the Shelve filter:
Lo BW : 3dB/oct to 12dB/oct
Hi BW : 3dB/oct to 12dB/oct
Range for the Cut filter:
Lo BW : Bessel or Butterworth
Hi BW : Bessel or Butterworth
Delay
Output Delay
Range: 0 - 200ms
Foreachofthesixoutputsit’spossibletoadjusttheDelay
time in Milliseconds.
Fine Adjust Output Delay
Range: 0 - 100 samples
InadditiontotheOutputDelayinmilliseconds,it’spossible
toadjusteachofthesixOutputDelaysinsamples
resolution.
The total Delay on an Output channel is the normal
msDelaysetting,PLUStheSampleDelaysetting.
The actual time a Delay set in Samples varies
dependingonrunningSampleRate.E.g.ifyouare
running48kHz,a48samplesdelayequals1ms,and
at96kHzitequals0.5ms.
