TC Electronic SYSTEM 6000 MKII Algorithm Manual

34
rEvErb - 3
This is a description of the parameters specific to the
Reverb-3algorithm.Itiscapableofmakinganexceptionally
clear Reverb sound using a very dense and natural
sounding Reverb Tail. Decay time can be controlled in
fourindividuallyadjustablefrequencybands.UsingDiffuse
and the Distance controls, sounds can be made in which
practicallynoEarlyReflectionsareheard.Addaslight
modulation to this to minimize room interaction with your
source material and you have - Reverb-3.
The Reverb-3 algorithm occupies:
@ Normal Sample Rate : 1/4 DSP Resource
@ Double Sample Rate : 1/4 DSP Resource
Algorithm Inputs/Outputs are distributed as follows:
Main Page
Main
Decay
Range: 0.3 to 30.0s
Reverberation Decay time.
Pre Delay
Range:1to150ms
Sets the time that passes before the first reflection
appears.
Distance
Range:0to15
The relative distance control varies the mix relationship
betweentheearlyandthelaterreflections.Whensetto“0”
moreoftheEarlyReflectionsareheard,similartobeing
close to the sound source in a room. As you increase
Distancetoward“15”moreofthelaterreflectionsareheard
=furtherawayfromthesoundsource.PracticallynoEarly
Reflectionsareheardat“15”.Pleasenotethatatvery
shortdistancestheEarlyReflectionsinteractwiththedirect
signalcreating‘chorus-like’colorationsjustasinrealrooms
with strong low-order reflections.
Diffuse
Range:1to9
The Diffuse parameter simulates when the reflections in
theroom“hit”moreorlessunevensurfaces.Withsmooth
wallslowdiffusiontakesplace.Wallsthatareuneven,with
manyangles,pocketsorwithdedicateddiffuserscausethe
reflectionstobreakintoahighnumberoflessidentifiable
reflections producing much higher diffusion. The Diffuse
parameter affects the quality of the diffuse field as well as
thespreadoftheEarlyReflections.
Diffuse Type
Range: Smooth1, Smooth2, Wow 1, Short1 and Short2
Thenaturalroommodepeakfrequenciesandthe
smoothness of the diffuse field are affected by this
parameter.UseSmooth1and2forlongdecays,whereas
the others are made for shorter Decay times and to
emulatethecharacteristicsofwellknownplates.
Hi Cut Freq
Range:500Hztoflat
Hi Cut filter, shelving type. Provides an overall Reverb high
frequency roll-off (6dB per octave) that is suitable for
makingthespacesoundwarmer.
Hi Cut Att
Range: -40 to 0.0dB
The attenuation control sets the high frequency roll
determinedbyHiCutFreq.
Levels
In Level
Range: Off to 0.0dB
SetstheleveloftheInputtotheReverbin0.5dBsteps.
Out Level
Range: Off - 0.0dB
SetstheOutputleveloftheReverbin0.5dBsteps.
E1 - E4
L
R
L
R
INPUT
OUTPUT
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
