TC Electronic SYSTEM 6000 MKII Algorithm Manual

37
rEv COrE - 2
Reverb
Early Reflections
Shape
Range:Hall,FanPrism,HShoe,ClubandSmall.
Select one of the above to simulate a specific room shape.
Size
Range: 0.040 - 4.000s
Scales the dimensions of the simulated space depending
ontheSHAPEchosen.Thespecificroomthatisbeing
simulatedisscaled1:1atSIZE=1.00.Thiscanthenbe
scaled up or down. Provided that the predelay setting is
relatively short, the corresponding volume of the simulated
space is changed radically with this control.
Xfeed
Range: On/off
With this parameter switched off, the Cross-feeds in the
EarlyReflectionswillbekilled.WithXfeedsettooff,
and the Width parameter set to 100%, a true stereo Reverb
is created. The effect from the left and the right channel will
be generated totally independently. The feature is especially
applicable for the film industry and post production suites.
Reverb
Lo Decay
Range:0.01to2.5times
Relative Decay time multiplier for low frequencies.
Lo Xover
Range: 20Hz to flat
Sets the frequency at which the transition from the low to
thelow-midfrequenciestakesplace.
Hi Decay
Range: 0.01 to 2.0 times
Multiplierforthehighfrequencies.IfHiDecayissetto0.5,
the Hi Decay time is half that of the nominal Decay setting.
Hi Xover
Range: 20Hz to flat
Sets the frequency at which the transition from the mid
frequenciestothehighfrequenciestakesplace.
Width
Range: 0 to 100 %
Sets the apparent stereo width of the reverberating part of
thealgorithm.At“0”thediffusefieldwillappeartobe
coming mainly from the center (mono compatible),
whereaswithWidthsetto“100”theL/Rreverberatorsare
independent.
Hi Cut Freq
Range:500Hztoflat
RollsoffthetopendasitenterstheReverbDiffuseField.
Usethisparameterto“darken”theroom.
Hi Cut Att
Range: -40.0 to 0.0dB
The attenuation control sets the high frequency roll
determinedbytheHiCutFreq.parameter.
Diffuse
Range:-50to50
This parameter gives you more or less Diffusion than the
algorithm designer intended for the given Decay time.
Foroptimumperformancethediffusionisautomatically
adjustedbehindthesceneswheneveryouchangeDecay
times. This parameter gives you the added control to vary
the Diffusion around this automatic setting.
