TC Electronic SYSTEM 6000 MKII Algorithm Manual

27
vss™ 6.1 - rEvErb
The VSS-6.1 Reverb algorithm occupies:
@ Normal Sample Rate : 2/4 DSP Resource
@ Double Sample Rate : 3/4 DSP Resource
Algorithm Inputs/Outputs are distributed as follows:
E1 - E4
L
R
C
LFE
SL
SR
SC
L
R
C
LFE
SL
SR
SC
INPUT
OUTPUT
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Main
Master Reverb
Master Decay
Range: 0.1 to 20s
AdjuststheMasterDecaytimefortheentireDiffused
image.IfyouneedtoadjusttheDecaytimeindividuallyper
channel, go to the Decay page and use the multipliers for
each channel.
Pre Delay
Range: 0 to 300ms
Pre Delay on the complete wet signal on all five
main-channels.
Fr. Hi Cut
Range:20Hzto20kHz
HiCutparameterfortheReverbDiffusefieldsintheFront
channels.
Surr. Hi Cut
Range:20Hzto20kHz
Hi Cut parameter for the Reverb Diffuse fields in the
Surround channels.
NotethatthisparametercanbelinkedtoFrontHiCuton
the Decay page.
Master Early
EachLocationType(seeSetuppage)hasapredefined
colorization. The Hi and Lo Color alter the default color of
the selected Location.
Lo Color
Range:-50to50
MasterLoColoradjustmentoftheEarlyReflections.
Hi Color
Range:-50to50
MasterHiColoradjustmentoftheEarlyReflections.
ER. Decrease - Restrictions in Order
Range: 0 to 100%
Reflection patterns in System 6000 are rendered to a high
order, but you may not always be interested in having a
fullemulation,e.g.ifthemicrophonealreadyhaspickedup
Choose Your Verb
MakesuretoreadtheReverbIntrointhismanualabout
distinguishing between Generic and Source Reverb types.
VSS-6.1isaGenerictype.Ittakesinacomplete
multichannelmixorstemandaddscomplexEarly
Reflections as well as uncorrelated diffused response
to the signal. VSS-6.1 is the first professional reverb to
acknowledgetheadvantagesof6.1roomsimulationto
coverwideaudienceslikeinacinema,ormakethemost
out of SACD 6.0 reproduction.
Theimprovementsover5.1mustbeheardtobebelieved,
somakesuretoenable6.1modewhenaseparate
Surround channel is available. The 6.1 mode is compatible
withDolbyEX,DTSESandSACD6.0.
VSS-6.1 Reverb Introduction
Reverb is added to the five or six main-channels (L,Center,
R,SL,SR,SC).TheLFE-channelispassedthroughtime
aligned but un-processed. The algorithm can be used at
sampleratesbetween44.1and96kHz.
Inputa5.1or6.1mixorstem,chooseaLocationtype
and Output format. If you want to position single-sources
intothe“VSS-6.1-Reverb”ordynamicallymovesources
aroundinthesurround-field,useeithertheSpacePan-5.1
algorithm or a surround panner that may already exist
within your mixing console.
High-qualityEarlyReflectionpatternsandfiveun-correlated
Reverbs are integrated in this algorithm. The extensive
EarlyReflectionpatternscanbeenabledtoenhance
localization and widen the sweet spot.
NoReverbisaddedtotheLFE
channel.TheLFEchannelistimealignedaccording
to processing Delay.
