TC Electronic SYSTEM 6000 MKII Algorithm Manual

68
TOOlbOX - 5.1
TheToolbox5.1isdesignedtosupportsurroundproduction.ThealgorithmoffersdifferentLevel,TestandBass
managementaswellasDownMixoptions.ItistypicallyusedincombinationwiththeMD5.1andVP-5.1algorithms.
Toolbox5.1isofferedasanintegratedpartoftheMD-5.1andVP-8algorithmsLicensepackages.
Level Trim
Solo
Mute
Bass
Manage-
ment
Level Trim
Ref. Levels
Solo/Mute
Format
Conversion
Limiting
Calibration
noise-tone
Input Output
The Toolbox algorithm occupies:
@ Normal Sample Rate : 1/4 DSP Resource
@ Double Sample Rate : 1/4 DSP Resource
Algorithm Inputs/Outputs are distributed as follows:
E1 - E4
L
R
C
LFE
SL
SR
Thru
Thru
L
R
C
LFE
SL
SR
Thru
Thru
INPUT
OUTPUT
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Main Page
Inputs
Mute
Range:Muted/Unmuted
Sets the Mute-status on the Input of of each of the 6
channels.ThedefaultsettingisUnmuted.
Solo
When a Solo button is selected, the Inputs of all the five
remaining channels will be set to Off, but they can be
selected as additional solo channels.
Outputs
Mute
Range:Muted/Unmuted
Sets the Mute-status on the Output for each of the 6
channels.
Solo
When a Solo button is selected, the Outputs of all the
five remaining channels will be set to Off, but they can be
selected as additional solo channels.
Format Page
Theformatconversionblockenablesyoutodown-mix5.1
signalstoLCRS,StereoorMonomix’sincludingLimiter
function.
Output Format
TheOutputFormatsectionisbasicallyusedtoconvert
Multi-channelsignalstootherformats.E.g.whengoing
froma5.0mixtoaStereoormonosignal.
Note that the Bass management is placed before this
formatconversioninthesignalchain.Usethedistribute
partoftheBass-Managementtoconvertfrom5.1to5.0
mix.
Signal Flow
Thru-Thruchannelsare“hardwired”withoutany
adjustmentoptions.
