TC Electronic SYSTEM 6000 MKII Algorithm Manual

32
rEvErb - 2
Main
Main
Decay
Range: 0.3 to 60.0s
Reverb diffuse field Decay time.
Pre Delay
Range: 0 to 200
Sets the time before the first reflection appears. Increasing
the Pre Delay will change the apparent position and, to
some degree, the size of the room.
Reverb Delay
Range: 0 to 100ms
Delay time on the Reverb diffuse field only. Where the Pre
Delay parameter sets the Delay time on the entire algorithm,
EarlyReflectionsaswellasdiffusefield,theReverbDelay
parameterworksonthediffusefieldonly.
Hi Cut Freq
Range:500Hztoflat
Hi Cut filter, shelving type. Provides an overall reverb high
frequency roll-off (6dB per octave), for creating a warmer
sound. Sets the Cut-off frequency of the overall Hi Cut filter
in 1/3-octave steps.
Hi Cut Att
Range: -40 to 0.0dB
The attenuation control sets the high frequency roll
determinedbyHiCutFreq.
Levels
Early Level
Range: -100dB to 0dB
TheOutputleveloftheEarlyReflections.WhenEarlyLevel
is set to off, the Reverb effect will consist entirely of Reverb
diffuse field.
Reverb Level
Range: off to 0.0dB
SetsthelevelofthereflectionenveloperelativetotheEarly
Reflectionsin0.5dBsteps.IfReverbLevelissettooffyou
will hear the initial reflections only.
In Level
Range: -100dB to 0dB
Sets the Input level of the algorithm.
Out Level
Range: -100dB to 0dB
Sets the Output level of the.
TheReverb2algorithminitiallycreatedfortheTCM5000
compliments most types of source material, however
experience has shown that the Reverb 2 algorithm is
especially good on percussive instruments, as it has a very
well-defined precise buildup. The Reverb 2 algorithm is a
Stereo In/Stereo Out Reverb.
The Reverb-2 algorithm occupies:
@ Normal Sample Rate : 1/4 DSP Resource
@ Double Sample Rate : 1/4 DSP Resource
Algorithm Inputs/Outputs are distributed as follows:
E1 - E4
L
R
L
R
INPUT
OUTPUT
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
