3. Installation
2016-04 IFU for Infinite 200 PRO No. 30052730 Rev. No. 1.6 49
3.2 Removal of the Transport Locks
CAUTION
REMOVE THE TRANSPORT LOCK
BEFORE OPERATING THE INSTRUMENT.
The instrument is delivered with the plate carrier locked into place, so that it
cannot be damaged. Before the instrument can be used the transport lock must
be removed using the following procedure:
1. Ensure that the instrument is disconnected from the main power supply.
2. Open the plate carrier compartment flap.
3. Remove the screws and pull the plate carrier out manually.
4. Remove the screws from the transport lock.
5. Remove the transport lock from the plate carrier.
6. The transport locks should be saved for further transportation purposes.
STOP
