The label above the main switch shows the on and off positions.
A - Shows where the switch is.
B - Shows which sides the ON and OFF (I and 0) positions are. The ON (I) / OFF (0)
positions may vary according to the equipment version. The correct positions
are given on the label on the equipment.
C - Shows the type of switch (two fixed positions).
When switching on for the first time you are requested to specify the power supply
voltage: the “voltage code: 230” message scrolls in the control panel. Type the
power supply voltage that the equipment is connected to with the number keys, as
indicated in the table below; then press ENTER to confirm and proceed.
Value to enter Rated power supply voltage
100 100 Vac
120 120 Vac
230 200÷240 Vac
03056007
03056009
A B
C
