13 Aligning the treadmill
When the equipment is running the treadmill must be centrally aligned in relation to
the frame (i.e. the writing on the belt must be equidistant from both sides). If it tends
to move to the right or left or is not centrally positioned, it needs aligning.
The alignment is done with the equipment running.
Turn the adjustment screw (A), on the side shown in the illustration, using the supplied
tool (B), until the writing is equidistant from both sides or the treadmill is aligned
with the marks in the two holes in the guard.
Warning
The treadmill realigns slowly: turn the adjustment screw ¼ or ½ a turn
and then check the result before turning it again.
02082039
02082002
B
A
02082061
