run excite
To adjust the brachial supports in height (F) use the lever (G); to rotate the lever
without changing the support height, pull it downwards and rotate.
To adjust the brachial supports horizontally (F) loosen the screw (H); once adjusted
tighten the screw.
Warning
The adjustments of the side and brachial supports must be performed by
a doctor or by qualified personnel.
H
G
H
F
