TOP 600 XTPRO: Service & Maintenance Manual - rev. 2.0
12.2. ADJUSTMENTS
12.2.1. PLAY OF SEAT BAR
Figure 12.2.1-1
Carry out the procedures described in paragraphs
12.1.1. “Disassembling seat” and 12.1.1.
“Disassembling the stem guard”
For both the adjusting pins a:
1. Loosen the stop nut b using a 17-mm
wrench.
2. Adjust the amount of play by means of the
adjusting pins, using a 10-mm Allen wrench.
Check the adjustment by moving the
seat bar up and down and making sure
that:
• when left in any position, it does not
slide down.
• the movement is smooth.
3. After completing the adjustment, lock down
what previously backed off.
Page 12.7
