Tektronix DSA8200 Series User Manual

Appendix C: Factory Default Setup Values
Miscellaneous Default
Values
The following t
able lists the Miscellaneous factory default setup values.
Command Default Values
AUTOSet:TYPE PERIOD
HARDCopy:FORMat
BMP
HARDCopy:INKSaver 0(OFF)
HEADer
0(OFF)
LOCk
FPANEL
VERBose
1(ON)
Status and Error Values
The following table lists the Status and Error factory default setup values.
Command Default Values
DESE
255
*ESE
0
*SRE
0
TDR Default Values
The following table lists the TDR factory default setup values.
Command Default Values
TDR:CH<x>:STEP:DESkew
0.000E+000
TDR:CH<x>:STEP:POLarity PLUSE
TDR:CH<x>:STEP:STATE 0(OFF)
TDR:CH<x>:UNIts RHO
TDR:INTRate 200
Trigger Default Values
The following table lists the Trigger factory default setup values.
Command Default Values
TRIGger:CH<x>:CLKRec:VALue NONE
TRIGger:CLKRec:SOUrce CH1
TRIGger:GATEd 0(OFF)
TRIGger:HIFreq 0(OFF)
TRIGger:HOLDoff
5.000E-006
TRIGger:INTRate
200
TRIGger:LEVel
0.000E+000
TRIGger:MODe AUTO
TRIGger:SLOpe RISE
TRIGger:SOUrce EXTDIRECT
DSA/CSA/TDS8X00/B Series Programmer Manual C-5
