Tektronix DSA8200 Series User Manual

Appendix C: Factory Default Setup Values
Vertical Default Values
The f ollowing t
able lists the Vertical factory default setup values.
Command Default Values
CH<x>:BANdwidth:VALue
1.000E+032
CH<x>:DESkew
0.000E+000
CH<x>:EXTAtten:MODe
LINEAR
CH<x>:EXTAtten:VALue
1.00E+000
CH<x>:FILTer:VALue NONE
CH<x>:OFFSet
0.000E+000
CH<x>:POSition
0.000E+000
CH<x>:SCAle
1.000E–000
CH<x>:UNIts AUTO
CURVe ASCII
DATa NA
DATa:DESTination
REF1
DATa:ENCdg ASCII
DATa:SOUrce CH1
DATa:STARt
1
DATa:STOP
500
REF<x>:POSition
0.
000000016
REF<x>:SCAle
5E
-10
SELect:CH<x>
0
SELect:CONTROl NONE,MAIN
SELect:MATH<x>
0
SELect:REF<x>
0
Waveform Database Values
The following table lists the Waveform Database fa ctory default setup values.
Command Default Values
WFMDB:DISplay:EMPHasis
50
WFMDB:DISplay:GRADing COLOR
WFMDB:DISplay:INVert 0(OFF)
WFMDB:WFMDB<x>:DISplay 0(OFF)
WFMDB:WFMDB<x>:ENABle
0(OFF)
WFMDB:WFMDB<x>:SOURce CH1,MAIN
Waveform Transfer Values
The following table lists the Waveform Transfer factory default setup values.
C-6 DSA/CSA/TDS8X00/B Series Programmer Manual
