Command Groups
Command
Description
MEASUrement:MEAS<x>:SOUrce<x>:
GATE<x>?
Returns the speciļ¬ed gate<x> settings for
measurement<x>
MEASUrement:MEAS<x>:SOUrce<x>:
GATE<x>:PCT
Pos
Sets or r eturns the gate endpoint in percent
MEASUremen
t:MEAS<x>:SOUrce<x>:
GATE<x>:POS
Sets or retu
rns the gate endpoint in waveform
units
MEASUrement:MEAS<x>:SOUrce<x>:
HILow?
Returns all high / low values for
measurement<x>
MEASUrement:MEAS<x>:SOUrce<x>:
HILow:ME
THod
Sets or returns the method for calculating
high / low
levels
MEASUrem
ent:MEAS<x>:SOUrce<x>:
HILow:TRACk:HIGH:ENABle
Sets or re
turns the tracking high level (on or
off)
MEASUrement:MEAS<x>:SOUrce<x>:
HILow:TRACk:HIGH:VALue
Sets or returns the high value used to
calculate a speciļ¬ed measurement on a
speciļ¬e
d source waveform
MEASUr
ement:MEAS<x>:SOUrce<x>:
HILow:TRACk:LOW:ENABle
Sets or
returns the tracking low level (on or
off)
MEASUrement:MEAS<x>:SOUrce<x>:
HILow:TRACk:LOW:VALue
Sets or returns the low value used to
calculate a speciļ¬ed measurement on a
speci
ļ¬ed source waveform
MEAS
Urement:MEAS<x>:SOUrce<x>:WFM
Sets
or returns the measurement source
waveform, and, optionally, the timebase on
which measurements a re taken
MEASUrement:MEAS<x>:SOUrce<x>:
WFM
DB:SIGType
Sets or returns the s ignal type of the
wav
eform database for the measurement
source
MEASUrement:MEAS<x>:SOUrce<x>:
WFMDB:STATE
Sets or returns the state of Use WfmDb for
measurement source (on or off)
MEASUrement:MEAS<x>:STATE Sets or returns the display of measurement
(
on or off)
M
EASUrement:MEAS<x>:STATIstics:CLEar
C
lears measurement statistics for
measurement<x>
MEASUrement:MEAS<x>:STDdev?
Returns measurement statistics standard
deviation value for measurement<x>
MEASUrement:MEAS<x>:TYPe Sets or returns the type of m easurement for
the speciļ¬ed measurement
MEASUrement:MEAS<x>:UNIts? Returns the units for the speciļ¬ed
measurement
MEASUrement:MEAS<x>:VALue? Returns the measurement value for the
speciļ¬ed measurement
MEASUrement:STATIstics:ENABle Sets or returns whether or not measurement
statistics are enabled (on or off)
MEASUrement:STATIstics:WEIghting Sets or returns measurement statistics
weighting for all measurements
2-30 DSA/CSA/TDS8X00/B Series Programmer Manual
