Command Groups
Command
Description
MEASUrement:MEAS<x>:ALL? Returns all measurement statistics values for
the measurement speciļ¬ed by x
MEASUrement:MEAS<x>:EYEWindow Sets or returns the percent of interval
between two e
ye crossings centered on the
middle of the region
MEASUrement:MEAS<x>:GATing:STATE Sets or r eturns the gating state (on or off) for
the measurement speciļ¬ed by x
MEASUrement:MEAS<x>:JITter Sets or returns the jitter-level crossing for
measureme
nt
MEASUrem
ent:MEAS<x>:MAXimum?
Returns measurement statistics maximum
value for
measurement <x>
MEASUrem
ent:MEAS<x>:MEAN?
Returns measurement statistics mean value
for measu
rement <x>
MEASUre
ment:MEAS<x>:MINimum?
Returns m easurement statistics minimum
value fo
r measurement <x>
MEASUr
ement:MEAS<x>:NOISe
Sets or
returns whether noise is measured
on the high or low level of the signal
MEASUrement:MEAS<x>:REFLevel<x>? Returns all reference level <x> settings for
measurement slot <x>
MEASUrement:MEAS<x>:REFLevel<x>:
ABSol
ute:HIGH
Sets or returns the top reference level in
absol
ute waveform units
MEAS
Urement:MEAS<x>:REFLevel<x>:
ABSolute:LOW
Sets
or returns the low reference level in
absolute waveform units
MEASUrement:MEAS<x>:REFLevel<x>:
ABSolute:MID
Sets or r eturns the mid reference level in
absolute waveform units
MEASUrement:MEAS<x>:REFLevel<x>:
MET
Hod
Sets or returns the method to calculate
ref
erence levels, either as a % of the h igh-low
range or in absolute vertical units
MEASUrement:MEAS<x>:REFLevel<x>:
RELative:HIGH
Sets or returns the high reference level as a
% of the high-low range
MEASUrement:MEAS<x>:REFLevel<x>:
R
ELative:LOW
Sets or returns the low reference level as a
%
of the high-low range
MEASUrement:MEAS<x>:REFLevel<x>:
RELative:MID
Sets or returns the mid reference level as a
% of the high-low range
MEASUrement:MEAS<x>:SETDefault Sets all measurement values to the
instrument default settings
MEASUrement:MEAS<x>:SOUrce<x>:
EDGE?
:EDGE? Returns all edge settings for the
speciļ¬ed measurement
MEASUrement:MEAS<x>:SOUrce<x>:
EDGE:DIRection
Sets or returns the direction (forward or
backward) that the instrument uses to look
for the rising or falling edge
MEASUrement:MEAS<x>:SOUrce<x>:
EDGE:SLOPe
Sets or returns the slope of the edges used
in delay time measurements
DSA/CSA/TDS8X00/B Series Programmer Manual 2-29
