Tektronix ECO8000 Series Service Manual

Replaceable parts
Table 5-2: Main
chassis and ECO8000 rear panel replaceable parts list
Fig. & index
number
Tektronix part
number Qty Name & description
5–2
Main chassis and ECO8000 rear panel
-1 200-5294-xx 1
CABINET, TOP MAIN CHASSIS, SAFETY CONTROLLED
-2 211-1194-xx 25
SCREW, MACHINE; M3 X 6MM, FLH BLACK, CROSS REC
-3 441-2743-xx 1
CHASSIS, MAIN BASE, SAFETY CONTROLLED
-4 174-6301-x
x
1
FRONT PANEL TO MAIN BOARD CABLE
-5
346-0120-x
x
2
STRAP, TIEDOWN; 5.5 L MIN, PLASTIC, WHITE
-6 174-6303-
xx
1
CABLE, RIBBON, LCD, 2X8, 0.050 P DISPLAY TO PROCESSOR FEMALE TO FEMALE
-7
211-A245-
xx
12
SCREW, MACHINE; M3 X 6 M M L, PNH, STL, NI PL, CROSS REC, W/NUT & LOCK WASHER
-8 878-0860-
xx
1
CIRCUIT BOARD ASSY; ECO PROCESSOR
-9 878-0861
-xx
1
CIRCUIT BOARD ASSY; ECO MAIN LOGIC
-10 407-5746
-x
1
BRACKET, PCB RETAINER, SD MODULE, ECO8000
-11 333-470
8-xx
1
REAR PANEL, ECO8000
-12 214-390
3-xx
8
SCREW, JACK; 4-40 X 0.312 EXT THD, 4-40 INT THD, 0.188 HEX, ZINC PLATED STEEL
-13 220-A09
5-xx
4
NUT, PLAIN, HEX: M3, STL, NI PL, W/EXT TOOHED WASHER
-14 131-66
43-xx
1
CONTACT, ELEC; GROUNDING, 0.169 L, 0.320 DEEP, ELECTROLESS NICKEL
-15 134-02
73-x
0–18
PLUG, HOLE COVER; BUTTON PLUG, DOUBLE-D HOLE, ECO8000
(quantity depends on product options; nine for each uninstalled channel module)
-16 210-1039-xx 9–27
WASHER, LOCK; 0.521 ID, INT, 0.025 THK, STEEL, ZINC FINISH, ECO8000
(quan
tity depends on product options; nine for each installed channel module)
-17 220-0497-xx 9–27
NUT, P
LAIN, HEX; 0.5-28 X 0.562 HEX, BRS, NI (NICKEL) PLATE, ECO8000
(quantity depends on product options; nine for each uninstalled channel module)
-18 348-
A156-01
1
GASKET, SHIELD; FINGER TYPE, BE-CU, 8.13MM W X 2.79MM H X 406.4MM L
-19 878-
0853-xx
1–3
CIRCUIT BOARD ASSY; ECO ANALOG CHANNEL MODULE (OPTION REF), UNTESTED, ECO8000
(quantity depends on product options; one for each installed REF/ELSW channel module)
-20 878-0855-xx 0–2
CIRCUIT BOARD ASSY; ECO SDI CHANNEL MODULE (OPTION HREF), UNTESTED, ECO8000
(qu
antity depends on product options; one for each installed HREF channel module)
-21 119-7929-xx 2
FIL
TER, EMI; AC LINE FILTER; 4.0A, 115-250VAC, 50/60HZ, IEC INPUT, LOCKING CORD, FAST-ON/SOLDER
LUG OUTPUT
-2
2
17
4-6312-xx
2
AC LINE TO COMBINER CABLE, SAFETY CONTROLLED
-2
3
17
4-6151-xx
2
CABLE ASSEMBLY (LINE FILTER TO GROUND, 16 AWG), SAFETY CONTROLLED
-
24
2
12-A041-xx
2
SCREW, MACHINE; M4 X 8MM L, PNH, STL, NI PL, CROSS REC, W/NUT & LOCK WASHER
-
25
2
11-1194-xx
2
SCREW, MACHINE; M3 X 6MM, FLH BLACK, CROSS REC
-
26
1
74-6302-xx
1
–4
CABLE ASSEMBLY 60 PIN, PCB MAIN TO PCB MODULE
(quantity depends on product model and options; one for each installed channel module)
-27 174-6045-xx 1
CABLE ASSEMBLY, BRIDGE-MARKER-CLOCK (14 POS MICRO-FIT, 12 INCH)
-28 211-1194-xx 4
SCREW, MACHINE; M3 X 6MM, FLH BLACK, CROSS REC
-29 352-1134-xx 4
LIGHT PIPE AND HOUSING, PWR SUPPLY SPG 8000, SAFETY CONTROLLED
5–6 ECO8000 Series Service Manual
