Tektronix ECO8000 Series Service Manual

Replaceable parts
Figure 5-3: ECO8020 rear panel
Table 5-3: ECO8020 rear panel replaceable parts list
Fig. &
index
numbe
r
Te ktronix part
numbe
r
Qty Name &
description
5-3
ECO8020 rear panel
-1 407-5745-xx 1
PCB RE
TAINER, ECO8020
-2 333-4710-xx 1
REAR PANEL, ECO8020
-3 211-
1194-01
10–4
0
SCREW, MACHINE; M3 X 6MM, FLH BLACK, CROSS REC
(quantity depends on product options; 10 for each installed channel module)
-4 134
-0277-xx
0–4
5
PLUG, HOLE C OVER; BUTTON PLUG, 0.312 HEAD DIA X 0.312 THK, ACCOM 0.250 DIA D HOLE, ECO8020
(quantity depends on product options; 15 for each uninstalled channel module)
-5
878
-0854-xx
1–4
CIRCUIT BOARD ASSY; ECO ANALOG HD BNC CHANNEL MODULE (OPTION REF), ECO8020
(quantity depends on product options; one for each installed REF/ELSW channel module)
-6 87
8-0856-xx
0–
3
CIRCUIT BOARD ASSY; ECO SDI HD BNC CHANNEL MODULE (OPTION HREF), ECO8020
(quantity depends on product options; one for each installed HREF channel module)
5–8 ECO8000 Series Service Manual
