Tektronix ECO8000 Series Service Manual

Replaceable parts
Table 5-1: Fron
t panel assembly a nd Power Supply module replaceable parts list
Fig. &
index
number
Te ktronix par
t
number Qty Name & description
5-1
Front panel assembly and Power Supply module
-1 367-0530-xx 2
HANDLE, BOW; AL,1.0 X 1.25, STAIN FINISH, SAFETY CONTROLLED
-2 335-3105-xx 1
LABEL, FRONT PANEL, SAFETY CONTROLLED, ECO8020
-3 335-3088-00 1
LABEL, FRONT PANEL, SAFETY CONTROLLED, ECO8000
-4 333-4709-xx 1
PANEL, FRONT
-5
260-2979-xx 1
LIGHT PIPE, FRONT PANEL EMAT
-6 260-2976-xx 1
SWITCH KEYPAD (ELASTOMERIC MAT, SET)
-7
878-0859-xx 1
CIRCUIT BOARD ASSY; ECO FRONT PANEL
-8 407-5779-xx 1
BRACKET, FRONT PANEL CONNECTOR RETAINER
-9 211-A245-xx 6
SCREW, MACHINE; M3 X 6 MM L, PNH, STL, NI PL, CROSS REC, W/PLAIN & SPLIT LOCK WASHER
-10 211-1276-xx 2
SCREW, MACHINE; 6-32 X 0.375, PNH, STL, ZNPL, T-15 TORX DR
-11 260-2976-xx 1
SWITCH KEYPAD (ELASTOMERIC MAT, SET)
-12 119-8090-xx 1
DISPLAY MODULE; LCD; 20 CHARACTERS X 2 LINES, TRANSFLECTIVE, 6:00 VIEW, STN, WHITE LED
BACKLIGHT
-13 348-2080-xx 1
GASKET, DISPLAY DUST SEAL
-14 211-1194-xx 4
SCREW, MACHINE; M3 X 6MM, FLH BLACK, CROSS REC
-15 354-0025-xx 2
RING, RETAINING; EXTERNAL,U/O 0.187 DIA SFT, ZINC PLATED STEEL
-16 335-3117-xx 1
LABEL, FRONT PANEL LEXAN RIGHT SIDE, NO TEXT
-17 213-0216-xx 2
THUMBSCREW; 10-32 X 0.85,0.375 OD HD, ZINC PLATED STEEL, W/SLOT
-18 333-4724-xx 1
PANEL, BLANK POWER SUPPLY
(not included when Option DPW is installed)
-19 335-3259-xx 1
LABEL, BLANK POWER SUPPLY
(not included when Option DPW is installed)
-20 650-5708-xx 1
POWER SUPPLY MODULE ASSEMBLY
(quantity is two when Option DPW is installed)
5–4 ECO8000 Series Service Manual
