Tektronix MDO3000 Series Program Manual

Appendix G: Application Module-enabled Commands
Application Mo
dule
Commands
DPO4AUTOMAX Extended Automotive Serial Triggering and Analysis Module. Enables triggering on packet-level i nformation
on CAN, LIN, and FlexRay buses as well as analytical tools such as digital views of the signal, bus views,
packet decodi
ng, search tools, packet decode tables with time-stamp information, and eye diagram
analysis software.
The DPO4AUTOMAX application module enables all the commands listed above for the DPO4AUTO
application
module, plus the following additional commands:
BUS:B<x>:F
LEXray:BITRate
BUS:B<x>:FLEXray:CHannel
BUS:B<x>:FLEXray:SIGnal
BUS:B<x>:
FLEXray:SOUrce
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:FLEXray:CONDition
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:FLEXray:CYCLEcount:HIVALue
SEARCH:S
EARCH<x>:TRIGger:A:BUS:B<x>:FLEXray:CYCLEcount:QUALifier
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:FLEXray:CYCLEcount:VALue
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:FLEXray:DATa:HIVA Lue
SEARCH:S
EARCH<x>:TRIGger:A:BUS:B<x>:FLEXray:DATa:OFFSet
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:FLEXray:DATa:QUA Lifier
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:FLEXray:DATa:S IZe
SEARCH:
SEARCH<x>:TRIGger:A:BUS:B<x>:FLEXray:DATa:VALue
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:FLEXray:EOFTYPE
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:FLEXray:ERRTYPE
SEARCH
:SEARCH<x>:TRIGger:A:BUS:B<x>:FLEXray:FRAMEID:HIVALue
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:FLEXray:FRAMEID:QUALifier
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:FLEXray:FRAMEID:VALue
SEARC
H:SEARCH<x>:TRIGger:A:BUS:B<x>:FLEXray:FRAMEType
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:FLEXray:HEADER:CRC
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:FLEXray:HEADER:CYCLEcount
SEARC
H:SEARCH<x>:TRIGger:A:BUS:B<x>:FLEXray:HEADER:FRAMEID
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:FLEXray:HEADER:INDBits
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:FLEXray:HEADER:PAYLength
TRIG
ger:A:BUS:B<x>:FLEXray:CONDition
TRIGger:A:BUS:B<x>:FLEXray:CYCLEcount:HIVALue
TRIGger:A:BUS:B<x>:FLEXray:CYCLEcount:QUALifier
TRI
Gger:A:BUS:B<x>:FLEXray:CYCLEcount:VALue
TRIGger:A:BUS:B<x>:FLEXray:DATa:HIVA Lue
TRIGger:A:BUS:B<x>:FLEXray:DATa:OFFSet
TRI
Gger:A:BUS:B<x>:FLEXray:DATa:QUALifier
TRIGger:A:BUS:B<x>:FLEXray:DATa:SIZe
TRIGger:A:BUS:B<x>:FLEXray:DATa:VALue
TR
IGger:A:BUS:B<x>:FLEXray:EOFTYPE
G-6 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
