Tektronix Phaser 740 User Manual

Service Guide
93
Key FRU Disassembly
This topic illustrates how to remove and replace key printer Field Replaceable Units
(FRUs). Refer to the later topic “FRU List” on page 113 for a list of the printer’s FRUs.
For more detailed removal/replacement procedures refer to the latest
Color Printer
Service & Support Resources CD-ROM
.
Printer cabinet
Removing cabinet covers
740-7-1
Upper rear
cover
Lower rear cover
Top cover
Left
side
cover
Retainer
hooks
Multi-purpose
tray
Door
Left door
Hinge
pin
Conical
spring
Hinge
frame
