120
Phaser 740 and 750 Color Printers
Table 5 Circuit board and electronics
Fig 5
parts
Part
number
Serial number
Effective Discont’d
Qty Name and description
1 118-9978-00 1 Laser driver board, Phaser 740
2 118-9898-00 1 High-voltage board
3 671-4380-80
671-4954-80
1
1
Image processing bd, Phaser 740
Image processing bd, Phaser 750
4
156-4758-10
156-4800-10
156-4811-10
156-4780-10
156-4830-00
156-4831-00
156-4832-00
1
1
1
1
1
1
1
Phaser 740
16-Mbyte RAM DIMM
32-Mbyte RAM DIMM
64-Mbyte RAM DIMM
128-Mbyte RAM DIMM
Phaser 750
32-Mbyte RAM SODIMM
64-Mbyte RAM SODIMM
128-Mbyte RAM SODIMM
5a
5b
5c
5d
671-4519-00
671-4527-00
671-4230-00
671-4231-00
1
1
1
1
Kanji Font DIMM, Phaser 740
Korean Font DIMM, Phaser 740
Simplified Chinese Font DIMM, P740
Traditional Chinese Font DIMM, P740
6a
6b
6c
671-4669-52
671-4671-52
671-4670-52
671-5183-50
671-5184-50
671-5185-50
1
1
1
1
1
1
Code ROM DIMM, Z740L,
Code ROM DIMM, 740 Base, Plus
Code ROM DIMM, 740 Extended
Code ROM DIMM, 750N
Code ROM DIMM, 750P/DP/DX
Code ROM DIMM, Kanji P750
7 671-4306-50 SCSI riser board, Phaser 740 only
8a
8b
8c
8d
8e
671-3994-00
671-4034-00
671-3932-50
386-7104-00
213-1118-00
650-3887-01
650-4145-00
1
1
1
1
2
1
1
10/100BaseT Ethernet card, 740 only
LocalTalk network card, 740 only
Token Ring network card
Blank cover plate (no card)
Blank cover plate thumbscrews
Internal IDE hard drive, P740 only
Internal IDE hard drive, P750 only
9 118-9559-00
116-0861-00
1
1
Cable, IP to engine board, P740
Cable, IP to engine board, P750
10 118-9527-00 1 Cleaning board
11 118-9903-00
116-0855-00
1
1
Engine control board (without
NVRAM chip), Phaser 740
Engine control board (without
NVRAM chip), Phaser 750
12
119-5924-00
119-5925-00
119-6294-00
119-6295-00
1
1
1
1
Phaser 740
Power supply (100 - 120 VAC)
Power supply (220 VAC)
Phaser 750
Power supply (100 - 120 VAC)
Power supply (220 VAC)
13 650-3886-01 1 Dallas Real Time Clock/NVRAM
Module (Phaser 740 only)
15 156-4768-00
163-1217-00
1
1
IP NVRAM EEPROM, Phaser 740
IP NVRAM EEPROM, Phaser 750
16 163-1147-01 1 BootROM/Printer ID, P740 only
17 116-0072-00
116-0859-00
1
1
Print engine EEPROM, Phaser 740
Print engine EEPROM, Phaser 750
118-9919-00 1 Lower tray circuit board
163-1307-01
163-1452-00
1
1
Print Engine Bd ROM, V24, 740 only
Print Engine Bd FW ROM,750 only
163-1440-00 1 NVRAM, Engine Control Bd, P750
