Tektronix Phaser 740 - Toner Cartridge Drive Unit; Accumulator Belt Home Position Sensor; Left Door Open Interlock Switch; Removing the Toner Cartridge Drive Unit, Home Position Sensor and the Left Door Interlock

148 pages

To Next Page

To Previous Page

104

Phaser 740 and 750 Color Printers

Toner cartridge drive unit

Accumulator belt home position sensor

Left door open interlock switch

Removing the toner cartridge drive unit, home position sensor and the left door

interlock switch

740-7-13

Toner cartridge

drive unit

Home position

sensor

Interlock

switch cover

Left door-opened

interlock switch
