Service Guide 85
4. Overlay and compare the pre-printed primary Color Density Samples in the
Color Printer User Guide to the selected colors on the midline of the print. If
any primary color does not match, overlay and compare to an alternate
color. Note the number, -10 to +10, referenced to the alternate choice.
5. Press the right arrow on the front panel to scroll to the Adjust <color>:+0
menu for the primary color you wish to change.
6. Press the arrow keys to increment the displayed value (from -10 to +10) to
match the alternate color selected from the reference print. Then press OK.
An “*” indicates the selected value.
7. Repeat Step 4 through 6 for any other color that needs adjustment.
8. Press Exit to leave the Color Calibration menus.
Manual color correction reference print
Cyan Magenta Yellow Black
-9
-7
-5
-3
-1
+1
+3
+5
+7
-6
-4
-2
0
+2
+4
+6
+8
+10
-9
-7
-5
-3
-1
+1
+3
+5
+7
+9
Color Reference Page
9698-18
-4
-2
0
+2
+4
+6
+8
+10
To Next Page
