Phaser 740 and 750 Color Printers

Table 3 Motors, drive units and fans

Fig 3

parts

Part

number

Serial number

Effective Discont’d

Qty Name and description

1 118-9897-00

116-0856-00

Toner cartridge selector/

paper-eject unit (Phaser 740)

Toner cartridge selector/

paper-eject unit (Phaser 750)

2 118-9551-00 1 Fan, power supply

3 118-9905-00 1 Toner cartridge drive motor

4 118-9514-01 1 Toner cartridge drive unit

5 118-9524-00 1 Fan, ozone ﬁlter

6 118-9553-00 1 Gear kit, Main motor drive

Motor compound gear

Intermediate compound gear

7 116-0940-00 1 Gear kit, Paper feeder/fuser

White joint gear,

Black compound gear,

4 fuser gears

8 118-9900-00 1 Main motor

9 118-9899-00

116-0862-00

1 Paper feed motor (Phaser 740)

paper feed motor (Phaser 750)

10 118-9524-00 1 Fan, fuser/toner cartridge
