Phaser 740 and 750 Color Printers

Table 4 Sensors, switches and ﬂags

Fig 4

parts

Part

number

Serial number

Effective Discont’d

Qty Name and description

1 118-9552-00 1 Switch, front/right door open

sensor

2 118-9547-00 1 Toner level sensor board

3 118-9558-00 Paper feed ﬂag kit

Paper tray empty

Multi-purpose tray entrance ﬂag

Jam at A ﬂag

Output tray full ﬂag

4 118-9913-00 1 Tray sensor board

5 118-9550-00 1 Left-side door-open switch

6 118-9519-00 1 Accumulator belt home-position

sensor assembly

7 118-9918-00

116-0854-00

1 Humidity/temperature sensor

(Phaser 740)

Humidity/temperature sensor

(Phaser 750)

8 118-9909-00

118-9910-00

Switch, main power (110 V)

Switch, main power (220V)
