Service Guide 25
Electrical specifications
Characteristic Specification
Primary line voltages 90 to 132 VAC (115 VAC or 100 VAC nominal);
198 to 264 VAC (220 VAC nominal)
Primary voltage frequency
range
50 to 60 Hz
Power consumption 130 watts (fuser off), 850 watts (fuser on) during Ready state,
950 watts during warm-up, 208 watts during printing,
45 watts during Energy Star state
Primary voltage fusing 110 VAC configuration – 8 and 10 amp
220 VAC configuration – 4 and 5 amp
Secondary DC voltages Image processor:
+ 5 VDC ± 0.25 (1A minimum, 6 A maximum)
Print engine:
+ 5V ± 0.25 (2.2 A max)
+ 24V ± 0.25 (3.0 A max)
RF emissions Both 110 and 220 VAC-configured instruments pass these
standards: FCC Part 15 Class B
VDE Class B
EN60555-2 Class A
VCCI (CISPR 22) Class B
Environmental specifications
Characteristic Specification
Best print quality
obtained
With in 15.5
o
to 25.5
o
C (60
o
to 78
o
F) and 30 to 65% RH
Temperature
Operating
Non-operating
Storage
15.5
o
to 32.5
o
C (60
o
to 91
o
F)
0
o
to 40
o
C (32
o
to 104
o
F)
-0
o
to 40
o
C (32 to 104
o
F)
Media should be acclimated 24 hours before using in the printer.
Humidity
Operating
Non-operating
10 to 80% relative humidity, non-condensing
10 to 90% relative humidity, non-condensing
Media should be acclimated 24 hours before using in the printer.
Altitude
Operating
Non-operating
0 to 2500 m (8,000 ft.) at 25
o
C
0 to 15000 m (50,000 ft.)
Vibration/shock
Operating
Non-Operating (vibration)
Non-operating (shock)
May drop any side or corner 50 mm (2 in.) without impairment of
subsequent operation.
On five mutually perpendicular axes: 0.5 g, 25-minute sweep, 5
to 200 to 5 Hz, 100 to 200 sec./sweep cycle. No resonant
frequencies below 50 Hz.
15 g, trapezoidal flared pulse, 20 msec each axis.
Acoustic Noise (operating) Average sound level (LEQ) is less than 53 dbA. Peak noise in
standby mode is 47 dbA.
