Quickly setting the probe attenuation to 1X or 10X
The Set To 1X and Set To 10X submenu items let you quickly set the probe
attenuation to either 1X or 10X.
1. Push the Vertical Menu button for the channel input that you want to set.
2. Push the Probe Setup side menu to display the Probe Setup submenu.
3. Use the Multipurpose knob to highlight either Set To 1X or Set To 10X
submenu item. Then click the Multipurpose knob to set that value.
Setting channel input parameters
52 TBS2000B Series Oscilloscopes User Manual
