Viewing Wi-Fi settings
Use this procedure to show the oscilloscope Wi-Fi settings.
Prerequisite: A Wi-Fi dongle is connected to the oscilloscope and Wi-Fi is turned
on. See Turning Wi-Fi on or off on page 157.
1. Push the Utility front-panel button.
2. Push the Config side-menu button.
3. Use the Multipurpose knob to select and click Wi-Fi Config.
4. Select and click Wi-Fi Settings. The oscilloscope shows the IP address
information and the Wi-Fi SSID and connection signal level information.
Viewing and selecting available Wi-Fi networks
Use this procedure to see the Wi-Fi networks the oscilloscope can detect, and
select the Wi-Fi network to use for communication.
Prerequisite: A Wi-Fi dongle is connected to the oscilloscope and Wi-Fi is turned
on. See Turning Wi-Fi on or off on page 157.
1. Push the Utility front-panel button.
2. Push the Config side-menu button.
Setting up the Wi-Fi network
158 TBS2000B Series Oscilloscopes User Manual
