Key Features
Key Features
You can use the TCP0030 current probe to make accurate measurements from DC to 120 MHz. The probe combines proven
Hall-effect technology with the new Tektro nix TekVPI oscilloscope interface. Key features include:
>120 MHz bandwidth, <2.92 ns rise time
AC/DC M easurement capability
50 A peak pulse current (pulse widths
<10 μs)
5 A and 30 A range settings
1 mA s ensitivity (on TekVPI oscilloscopes
that support the 1 mV/div setting)
1% DC Accuracy (typical)
One-button degauss/autozeroing
Probe control through the TekVPI
oscilloscope menus or remotely through
the oscilloscope
Direct scaling and unit readout on host
instruments
AC coupling (on TekVPI oscilloscopes that
support AC coupling)
TCP0030 C urren t Probe Instruction Manual 1
