Performance Verification
Equipment Required
Table 6 lists the equipment required for the performan ce verification procedure.
Table 6: Test equipment
Description and quantity Performance requ ire ment Recommended example
1
Oscilloscope TekVPI interface, 500 MHz or greater bandwidth Tektronix DPO4000
High Amplitude Pulse
Generator
Risetime <500 ps, pulse width >100 ns, amplitude
>10 Vpp into 50 Ω
Picosecond Labs 2600
Calibrator DCV: 0.2% accuracy, 0 to ±1.5 V, squa re wave output
ACA: 0.25% accuracy, 0 to ±6 A, square wave outpu t
Wavetek 9100
DC Current loop 5 turns 18 AWG coated wire on 3 inch form See instructions that follow
HF Current loop 50 Ω ±0.5%, BNC male
015-0601-50
BNC-to-Dual banana adapter
103-0090-00
BNC Cable 50 Ω , 0.76 m (3 0 in) length
012-0117 -00
1
Nine-digit part numbers (xxx-xxxx- xx) are Tektronix part numbers.
TCP0030 C urren t Probe Instruction Manual 51
