Specifications
Typical Characteristics
Typical characteristics describe typical but not guaranteed performance.
Table 2: Typical electrical characteristics
Characteristic Description
Maximum continuous current — DC a nd
Low frequency (See Figure 3.)
5 A Range: 5 A RMS
30 A Range: 30 A RMS
Maximum peak current (See Figure 3.)
50 A maximum peak pulse
Displayed RMS Noise ≤75 µA RMS. (Limit measurement ban dwidt h to 20 MHz)
Insertion impedan ce
(See Figure 2.)
Aberrations
<50 ns: ≤10% p-p >50 ns: ≤5% p-p
Signal delay
~14.5 ns
Maximum voltage on bare wire Use on insulated conductors only
Maximum Amp·Second p roduct (See
graph on page 49.)
5 A Range: 50 A·µ s
30 A Range: 50 0 A·µs
TCP0030 C urren t Probe Instruction Manual 41
