Specifications
Warranted Characteristics
Warranted characteristics de scribe guaranteed performance within tolerance limits or certain type-t ested requirements. Warranted
characteristics that have checks in the Performance Verification section are marked with the
symbol.
Table 1: Warranted electrical characteristics
Characteristic Description
DC gain accuracy
<3% (typical < 1% at +23 °C, ± 5 °C)
Rise time (10% to 90%)
≤2.92 ns
Bandwidth
DC to 120 MHz
40 TCP0030 Current Probe Instruction Manual
